OVERVIEW
Holley now offers offers a line of high performance Drop-in fuel modules to cover a wide ranges of vehicles from sports cars to pickup trucks. These Drop-in modules have been designed to the highest quality standards to provide increased performance and fuel efficiency for most stock, turbo, and supercharged applications capable of supporting 550+ horsepower.
Features:
- Complete drop-in fuel module assembly
- Integrated fuel storage and filtration technology
- Built in, pre-calibrated fuel level sensors
- Plug and play wiring harnesses
- Capable of supporting 550+ hp right out of the box
- Designed for return line and pulse width modulation (PWM)
-
SPECS
Application 2005-2009 Mustang GT V8 4.6L Average Flow Rating 300 LPH Brand Holley Category Air and Fuel Delivery Connector Color White Connector Gender Male Connector Quantity 1 Emission Code 5 Free Flow GPH 79 Free Flow LPH 300 Fuel Filter Included Yes Fuel Sending Unit Included Yes Fuel System EFI Fuel Tank Pressure Sensor Included No Fuel Type Gasoline Gasket Or Seal Included Yes Grade Type Performance Height Standard Housing Material Plastic In Tank or External In Tank Inlet Quantity None Internal Or External Strainer External Lock Ring Included No Maximum Pressure 60 PS Mounting Hardware Included No Negative Ground Yes Outlet Quantity One Outlet Size 5/16 Barb Outlet Type Barb Part Type Fuel Pump Module Assembly Product Type Fuel Pump Module Pump Type Electric Regulator Included No Resistance Ohms Empty 15 82 Resistance Ohms Full 160 82 Sub Category Fuel Pumps and Related Components Universal Or Specific Fit Specific Voltage 12 2H Warranty Manufacturer's Limited 90 Day Warranty Wire Harness Included No Wire Quantity 4 UPC 090127718001 Part Number 12-949
