OVERVIEW
Flowtech Headers are the perfect blend of quality, performance, and value. These 1-3/4" shorty style race headers fit the very popular 5.0L V8 for the Fox-Body Mustang platform. The 1-3/4" tube size is the perfect upgrade for stroker motors and engines that have limited clearance issues and still require a free flowing header.
Features:
- Mandrel-bent 409 Stainless Steel tubes provide consistent tubing diameters for smooth flow and increased exhaust velocity
- Heavy duty 16-gauge tubing for increased strength and durability
- Smooth transition, 1-3/4” diameter primary tubes are used for increased exhaust flow increasing performance and improving throttle response
- OE style 2-1/2” ball and socket collector connects to factory exhaust head pipe with no cutting or welding
- TIG-welded, machined 3/8” header flange for a leak-free seal and maximum strength
- Premium aluminum header gaskets included
- Available finishes include: High Temp Black Painted, Ceramic Coated and Polished
- These headers are a must upgrade if you are using a cold air intake, cat-back exhaust system or performance cylinder head
SPECS
Air Injection Tubes No Bolt Size 3/8-16 x 3/4 IN Bolts Included Yes Brand Flowtech Exhaust California Proposition 65 Yes CARB (California) Compliant No Catalytic Converter Quantity 0 Category Exhaust Collector Attachment 2-Bolt Flange Ball and Socket Flange Collector Diameter 2 7/8 @ Collector, 2 1/8 ball flare opening IN Collector Port Diameter 2.50 IN Collector Reducer Included No Collector Reducer Outlet Diameter N/A Color Black Design Shorty Drive 2WD EGT Port No Emission Code 4 Engine Ford Small Block Finish Painted Flange Thickness 0.375 IN 3/8 IN Gasket Or Seal Included Yes Grade Type Performance Header Series Shorty Header Style Shorty Material Mild Steel Mounting Hardware Included Yes Oxygen Sensor Port No Part Type Exhaust Header Port Shape Rectangle Primary Tubing Diameter 1 3/4 IN 1.75 IN Product Type Headers Quantity Sold as a Pair Sheen Level Satin Sub Category Exhaust Manifolds Tube Wall Thickness 18 GU UPC 090127011812 Part Number 12147FLT
