OVERVIEW
Holley is now offering budget friendly fabricated intake manifolds for LS, Small Block Chevy and Small Block Ford engines in carbureted and EFI versions!
Features:
- 3mm (1/8") thick T6061 sheet aluminum construction for maximum durability
- 100% TIG welded for strength and durability
- Silver finish creates high impact under-hood styling
- Intake runners with tapered top is designed to increase air velocity and more evenly distribute airflow to all 8 cylinders improving performance and throttle response
- Product includes all gaskets and hardware for a hassle-free installation
- 90mm throttle bore opening for increased air flow
- Includes 3/8" Fuel rail kits (Sniper logo laser engraved)
SPECS
| Basic Operating RPM Range | 2200-6800 RPM |
|---|---|
| Brand | Holley Sniper EFI |
| Carburetor Flange | N/A |
| Carburetor Quantity | N/A |
| Carburetor Studs Included | No |
| Category | Sniper EFI Intakes |
| CNC Ported | No |
| Color | Polished |
| Construction | Fabricated |
| Cylinder Head Port Shape | Oval with dimple |
| Deck Height | 8.937 IN |
| EGR Port | No |
| Emission Code | 4 |
| Engine | Ford Coyote |
| Flange Style | N/A |
| Front Maximum Height | 7.165 IN |
| Fuel Injectors Included | No |
| Fuel Rail(s) Included | Yes |
| Gasket Or Seal Included | Yes |
| Grade Type | Performance |
| Injector Style Provision | EV6 USCAR |
| Intake Port Gasket(s) Included | Yes |
| Material | Aluminum |
| Nitrous Bung(s) Included | No |
| Plenum Finish | Polished |
| Product Type | Intake Manifold |
| Rear Maximum Height | 6.574 IN |
| Removable Runners | No |
| Removable Top/Lid | No |
| Runner Length | 5.709" (145mm) |
| Single Or Dual Plane Type | Single Plane |
| Style | EFI |
| Throttle Body Bore Diameter | 90 MM |
| Throttle Body Gasket Included | Yes |
| Throttle Body Included | No |
| Throttle Bore | 90mm |
| Vacuum Ports | (3) 1/8"-28BSPT & (1) 1/4"-19BSPT |
| Warranty | Manufacturer's Limited 90 Day Warranty |
| UPC | 847875006696 |
| Part Number | 829031 |
